Amplification and power supply
| Amplification class | Class D |
| Output power, all channels loaded | 4 x 1000 W at 4 ohms 4 x 1000 W at 8 ohms |
| Power supply model | Universal Switched Mode Power Supply (SMPS) with Power Factor Correction (PFC) |
| Mains rating | 100 V – 240 V ±10%, 50-60 Hz |
DSP
| Digital Signal Processor (DSP) | SHARC 32-bit, floating point, 96 kHz sampling rate |
| I/O routing | Flexible 4×4 routing matrix |
| Per output channel | Built-in EQ station with 8 IIR, 4 FIR linear phase EQ filters Array morphing, Air absorption compensation filters Internal IIR and FIR EQ algorithms L-DRIVE advanced system protection Output delay from 0 to 1000 ms |
Technologies
| loudspeaker management | L-DRIVE advanced system protection |
Latency
| standard latency (analog/digital inputs) | 3.84 ms |
| low latency (analog/digital inputs) | 0.84 ms |
Inputs
| AVB | 4 channels from 1 stream (of up to 8 channels) |
| AES/EBU | 4 channels AES/EBU (2 x AES3) with SRC |
| analog | 4 channels |
| connections | 2 etherCON 1 Gb/s I/O+ control 4 female 3-pin XLR (2 x switching analog/AES3) 4 male 3-pin XLR links |
Outputs
| loudspeaker connections | 4 x SpeakON |
Circuit protection
| Mains and power supply | Over and under voltage / over temperature / overcurrent |
| Power outputs | Overcurrent / short circuit / over temperature |
Interface
| display/indicators | LCD and LED’s |
| navigation | Rotary encoder, power and mute keys |
Control and monitoring
| L-Acoustics remote control software | LA Network Manager |
| Third-party management solutions | QSC® / SNMP / Extron® / Crestron® |
Operating conditions
| Temperature | 0º C / 32º F to +50º C / 122º F |
Physical data
| Height | 2U |
| Weight | 11.3 kg / 24.9 lb |
| Protection rating | IP30 |
Dimensions
