Amadeus C 10

ACOUSTICAL SPECIFICATIONS

Amplitude linearity (± 3 dB) 75 Hz – 20000 Hz
Operating frequency range (-6 dB) 65 Hz – 20000 Hz
Cut-off frequencies (-10 dB) 57 Hz – 20000 Hz
Number of ways 2
Sensitivity 96 dB
Maximum SPL 126 dB
Horizontal coverage 100°
Vertical coverage 100°

TECHNICAL SPECIFICATIONS

Nominal impedance 8 Ω
AES power handling 400 W
Program power handling 800 W
Peak power handling 1000 W
Transducer (LF) 1 x 10″
Transducer (HF) 1 x 1.75″
Enclosure type Bass-Reflex
Crossover type Passive

CONNECTOR AND BUTTON SPECIFICATIONS

Input connectors (Analog) 1 x speakON NL4MP

PHYSICAL SPECIFICATIONS

Height 336 mm
Width 336 mm
Depth 260 mm
Weight 13 kg
Handles 2
Rigging 2 x M8 threaded inserts for optional U-Bracket
Rigging 2 x M8 threaded inserts for optional mounting adapter
Standard colour codes for cabinet 9005/9010/1013/7040/7030/5011
Standard colour codes for fabric 9005/9006/9010/1035/1036

PROPRIETARY ACCESSORIES

Amadeus LYRE C 10 U-Bracket for C 10
Atelier 33 FA2C10 Flight Case featuring casters with brakes for two Amadeus C 10

COMPATIBLE ACCESSORIES

195/8 Slip-on adapter for speaker stands with tube diameter of 35 mm
24281 Slip-on adapter for speaker stands with tube diameter of 35 mm
