LIGHT SOURCE
- Source: 280W RGB + Warm White LED
- CCT: @full 6.000
- Luminous flux: (7,6°) 2’888 lm – (43°) 3’038lm @full
- Lux: (7,6°) 6’631 lx – (43°) 532lx @5 m full
- CRI: 96 @3.200 K; 93 @5.600 K
- R9: 92 @3.200 K; 92,7 @5.600 K
- TLCI: 84 @3.200 K; 84 @5.600 K
- TM30 Rf: 91 @3.200 K; 91 @5.600 K
- TM30 Rg: 104 @3.200 K; 105 @5.600 K
- Source life expectancy: > 70.000 h
OPTICS
- Zoom: 7,6° – 43° motorised linear zoom
- Lens diameter: 125mm / 4.92”
- Lens type: high-quality glass lens optics
COLOUR SYSTEM
- Colour mixing: RGB + Warm White
- CCT: CCT control, + / – green correction, tungsten emulation
- White presets: 2.800 K – 8.000K
- Colour wheel: virtual colour wheel with macros
- Macros: several pre-built macros with adjustable speed
DYNAMIC EFFECTS
- Special features: linear crossfade channel from any white to any colour; virtual CTO on colours
BODY
- Hardware on-board: sockets for quick-Lock Omega bracket (clamp included)
- Pan angle: 540°
- Tilt angle: 250°
- Pan/Tilt resolution: 8/16bit
- Feedback: automatic repositioning after accidental movement
- Body: aluminium die-casting
- Body colour: black
CONTROL
- Protocols: DMX512, RDM, Art-Net, W-DMX
- DMX channels: 13 / 15 / 16 / 18 / 22 / 23 / 27channel
- Wireless Control: included, wireless solution receiver
- RDM: RDM for remote monitoring and settings
- Display: LCD high resolution colour display with autoflip
- Firmware upgrade: yes, via USB – DMX interface (UPBOX1) not included
ELECTRONICS
- Dimmer: linear 0 ~ 100% electronic dimmer
- Dimmer curves: selectable dimming modes available
- Strobe / shutter: 1 – 30 Hz, electronic
- Display battery: self-charging battery backup
- Operating temperature: -10° ~ +45°
- LED Control: flicker free frequency with adjustable PWM
ELECTRICAL
- Mains power supply: 100-240V – 50/60Hz
- Max power consumption: 240W
- Output (at 230V): 8 units on a single power line
- Power factor: >0,95
PHYSICAL
- IP rating: 20
- Cooling: combination of heat pipe cooling system and low noise fan
- Suspension and fixing: any position with quick-lock omega brackets
- Signal connection: Amphenol XLR 5p IN/OUT connectors
- Data connection: Art-Net RJ45 IN/OUT
- Power connection: Seetronic powerCON waterproof IN/OUT connectors
- Dimensions (WxHxD): 308x448x230mm / 12.13”x17.64”x9.06”
- Weight: 13,6kg / 29.98lbs
CERTIFICATIONS / APPROVALS
- Certifications / Approvals: CE, UKCA, RCM, cTUVus, FCC
- 1 x PIXIEWASHXB
- 1 x 1,5 meters power cable (BARE END – SEETRONIC IP65 power connector)
- 2 x OS24
- User Manual
