Amadeus ML 18 X

ACOUSTICAL SPECIFICATIONS

Amplitude linearity (± 3 dB) 35 Hz – 350 Hz
Operating frequency range (-6 dB) 32 Hz – 350 Hz
Cut-off frequencies (-10 dB) 29 Hz – 350 Hz
Number of ways 1
Sensitivity 100 dB
Maximum SPL 134 dB
Horizontal coverage 360°
Vertical coverage 360°

TECHNICAL SPECIFICATIONS

Nominal impedance 8 Ω
AES power handling 1000 W
Program power handling 2000 W
Peak power handling 2800 W
Transducer (LF) 1 x 18″
Enclosure type Bass-Reflex

CONNECTOR AND BUTTON SPECIFICATIONS

Input connectors (Analog) 2 x speakON NL4MP

PHYSICAL SPECIFICATIONS

Height 504 mm
Width 873 mm
Depth 723 mm
Weight 67 kg
Handles 4
Rigging 1 x screw receptacle for satellite pole
Standard colour codes for cabinet 9005/9010/1013/7040/7030/5011
Standard colour codes for fabric 9005/9006/9010/1035/1036

PROPRIETARY ACCESSORIES

Atelier 33 FA1ML18X Flight Case featuring casters with brakes for one Amadeus ML 18 X
