Prolights LumiPix 16H

16×12 W high power LED pixel batten with RGBWA + UV mixing

LumiPix 16H is a 100 cm linear LED batten. Designed for professional use utilising an innovative optical system combined with a new light source that performs: 6 primary colours – RGBWAP full colour – granting unprecedented chromatic performance. The super-slim design combined with its extreme colour precision and light output, make LumiPix 16H a flexible and versatile solution for every type of application or for use in venues, as the architectural, cyclorama, wall-washer, pixel effect or blinder.

Thương hiệuProLights
So sánh
Thêm vào yêu thích
Danh mục: Thẻ:
Mô tả

LIGHT SOURCE

  • Source: 16x12W RGBWAP LEDs
  • Luminous flux: 4’159lm
  • Lux: (15°) 2’692lx @3 m full
  • Lux: (25°) 1’907lx @3 m full
  • Source life expectancy: > 50.000 h

OPTICS

  • Beam angle: 23°
  • Field angle: 37°
  • Lens diameter: 42mm / 1.65”
  • Additional optics: 25° and 45° (optional)

COLOUR SYSTEM

  • Colour mixing: RGBWAP / FC
  • White presets: 3.200 K -10.000K
  • Colour wheel: virtual colour wheel with macros
  • Macros: several pre-built pixel macros with adjustable speed

DYNAMIC EFFECTS

  • Static mode: selection of static colour
  • Manual mode: manual adjustment of colour
  • Auto mode: built-in programs with execution speed adjustment

BODY

  • Body: sturdy aluminum profile
  • Body colour: black

CONTROL

  • Protocols: DMX512
  • DMX channels: 6 / 8 / 12 / 96 / 101channel
  • Pixel control: pixel2pixel control
  • Display: LCD display
  • Firmware upgrade: yes, via USB – DMX interface (UPBOX1) not included
  • Master/Slave: for synchronised operation of more units linked in a chain

ELECTRONICS

  • Dimmer: linear 0 ~ 100% electronic dimmer
  • Dimmer curves: 4 selectable dimming modes available
  • Strobe / shutter: 1-25 Hz, electronic
  • Operating temperature: -10° ~ +45°
  • LED Control: flicker free frequency with adjustable PWM

ELECTRICAL

  • Mains power supply: 100-240V – 50/60Hz
  • Max power consumption: 160W
  • Max power consumption (at 120V): 165W
  • Output (at 230V): 12 units on a single power line
  • Power factor: pF 0,95 @120 V – pF 0,90 @230 V

PHYSICAL

  • IP rating: 33
  • Cooling: passive cooling and fan-free
  • Suspension and fixing: bracket for hanging and positioning
  • Signal connection: XLR 3p + 5p IN/OUT connectors
  • Power connection: Neutrik powerCON IN/OUT connectors
  • Dimensions (WxHxD): 1.000x180x63mm / 0.04”x7.09”x2.48”
  • Weight: 5,1kg / 11.24lbs

CERTIFICATIONS / APPROVALS

  • Certifications / Approvals: CE, UKCA, RCM

BOX CONTENT

  • 1 x LUMIPIX16H
  • 1 x 1,5 meters power cable (BARE END – NEUTRIK POWERCON)
  • 2 x side floor brackets
  • User Manual
