LIGHT SOURCE
- Source: 12x10W RGBW / FC LEDs
- Luminous flux: (10°) 1’450 lm – (60°) 1’786lm
- Lux: (10°) 3’144 lx – (60°) 249lx @5 m full
- Source life expectancy: > 50.000 h
OPTICS
- Zoom: 10° – 60° motorised linear zoom
- Lens type: plano-convex lens path
COLOUR SYSTEM
- Colour mixing: RGBW / FC
- Colour wheel: virtual colour wheel with macros
- Macros: built-in white presets
DYNAMIC EFFECTS
- Static mode: selection of static colour
- Manual mode: manual adjustment of colour
- Auto mode: built-in programs with execution speed adjustment
BODY
- Body: sturdy die-cast aluminium body
- Body colour: black
CONTROL
- Protocols: DMX512
- DMX channels: 5 / 7 / 10channel
- Display: Graphic User Interface
- Firmware upgrade: yes, via USB – DMX interface (UPBOX1) not included
- Master/Slave: for synchronised operation of more units linked in a chain
ELECTRONICS
- Dimmer: linear 0 ~ 100% electronic dimmer
- Dimmer curves: 4 selectable dimming modes available
- Strobe / shutter: 1 – 28 Hz, electronic
- Operating temperature: -10° ~ +40°
- LED Control: flicker free operation
- Selectable PWM: 600 ~ 25.000 Hz
ELECTRICAL
- Mains power supply: 100-240V – 50/60Hz
- Max power consumption: 120W
- Output (at 230V): 12 units on a single power line
- Power factor: > 0,94
PHYSICAL
- IP rating: 30
- Cooling: active, silent operation
- Suspension and fixing: double hanging bracket suitable for safe hanging and for floor positioning
- Signal connection: XLR 3p + 5p IN/OUT connectors
- Power connection: Neutrik powerCON IN/OUT connectors
- Dimensions (WxHxD): 262x350x261mm / 10.31”x13.78”x10.28”
- Weight: 5,5kg / 12.13lbs
CERTIFICATIONS / APPROVALS
- Certifications / Approvals: CE, UKCA, RCM
- 1 x VERSAPAR
- 1 x 1,5 meters power cable (BARE END – NEUTRIK POWERCON)
- User Manual
